OPTICS
• Beam aperture: 4,5°
• 85% optic efficiency
• High-efficiency 67 mm PMMA optics
LIGHT SOURCE
• 7 multi-chip 15 Watt LED sources
• Light output: up to 2,500 lumen
• Luminous intensity: 262,500 cd
• Rated sources life: up to 50,000 hours
• Flicker free sources management, suitable for TV applications and all video recorded events
MOVEMENT
• Continuous PAN and TILT rotation
• Extremely accurate positioning
• Moving-head operated via either 8 or 16 bit resolution
• High-resolution stepper motors operated via microprocessors ensure extreme accuracy and smooth movements.
• PAN and TILT automatic repositioning
COLOURS
• Sophisticated 4 colours RGBW mixed, reaching high Colour Rendering Index
• Uniform light beam with no colour shadows, and rich saturated and pastel colour-hues
• 4.29 billion colours (8 bit resolution)
• Virtual colour wheel, including most usuals white colour temperature presets
• Dynamic colour macro effect with variable speed
DIMMER / STROBE
• Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation
• White or colourstrobe effect,with speed adjustment from 1 to 25 flashes per second
SOFTWARE FACILITIES
• Local DMX addressing of the luminaire and its optional parameters through its built-in LCD panel control
• Remote DMX addressing of the luminaire and its optional parameters through a standard RDM
DMX controller
• Built-in pattern effects with speed and fade controls for scenic applications
• Information menu including hour counter, temperature, software version
HARDWARE FACILITIES
• Graphic LCD display for addressing and special functions settings, with flip function
• 6 menu buttons to set the functions
• Over temperature protection
• Integrated LumenRadioTM’s wireless CRMX RDM receiver
• XLR 5 pin male and female connectors for DMX connection
• Ethercon RJ45 IN / OUT connectors for ArtNet & sACN connection
• PowerCON TRUE1 male and female connectors for power connection
|
|
CONTROL
• DMX 512 protocol, through DMX cable or wireless system
• DMX-RDM compatible
• Stand-alone mode and Master/Slave modes
• ArtNet & sACN protocol through Ethernet cable
• Local control panel, with LCD display
• Choice of 3 DMXmodes(from18 to 44 DMX channels)
POWER SUPPLY
• Electronic supply with active PFC
• 110 to 240 Volts - 50/60Hz
• Power 200 Watt max
COOLING SYSTEM
• Advanced cooling system
• Self adjusting variable speed fansfor quiet operation (Auto mode)
• Selectable auto, stage & studio ventilation modes
• Safety protection against temperatures excesses
HOUSING
• Moving-head skeleton made of aluminium and steel metal plates
• Heatsinks in aluminium, satin finish
• Moulded covers in self extinguishing fire retardant ABS PC (V0 class)
• Two sides handles for transportation
• Four strong wide feet for better stability
• IP20 protection rating
• Exterior finish: black (Carbon)
INSTALLATION
• Fastening brackets system: two Omega ¼ turn brackets designed for use with standard clamps
• Mounting points: two ¼ turn locking fittings allowing installation of Omega brackets on luminaire
• Safety cable attachment point
OPERATING PARAMETERS
• Operating positions: all (device on floor or fixed to a support)
• Maximum permitted ambient temperature (Ta max): 45°C (113°F)
• Minimum permitted ambient temperature (Ta min): -10°C (14°F)
• Minimum usage distance: 0.2 m (8 inches)
COMPLIANCE
EU (EMC)
• EN 55015 (2006) - EN 55015 A2 (2009)
• EN 61547 (2009) - EN 61000-3-2 (2006)
• EN 61000-3-2 A2 (2009) - EN 61000-3-3 (2008)
EU (LVD)
• EN 60598-1 (2008) - EN 60598-2-17 (1989)
• EN 60598-2-17 A2 (1991)
SIZE
• Product: 571 x 266 x 184 mm (l x h x d)
• Flight-case foam: 625 x 295 x 250 mm (l x h x d)
WEIGHT
• Product: 12.1 KG
PRODUCT CODES
• 015250: MAGICBLADE-R CREATIVE SOLUTION
|
