LIGHT SOURCE
Source: 91x3W RGB + lime LEDs
CCT: @full 5.000K
CRI: 86 @ 3200K
R9: 64 @ 3200K
Luminous flux: (5°) TBD; (10°) TBD; (14°) 4'619 lm; (19°) 5'133 lm; (26°) 6'100 lm; (36°) 5'970 lm; (50°) 5'596 lm; (70°) TBDlm @full
Lux: (5°) TBD; (10°) TBD; (14°) 4'321 lx; (19°) 2'567 lx; (26°) 1'711 lx; (36°) 873 lx; (50°) 462 lx; (70°) TBDlx @5 m full
Source life expectancy: > 50.000 h
Other: TM30: 83 @ 3200K; TLCI: 75 @ 3200K
OPTICS
Beam angle: optional 5° / 10°/ 14° / 19° / 26° / 36° / 50° / 70° / zoom 15°-30° / zoom 25°-50°
Lens type: high-quality glass lens optics
Focus: manual
COLOUR SYSTEM
Colour mixing: RGB + lime / full colour
CTC: CTC control through dedicated DMX channel
White presets: 2.700 K ~ 10.000K
Colour wheel: virtual colour wheel with presets
Macros: several pre-build pixel macros with adjustable speed
DYNAMIC EFFECTS
Shutter system: 3 layers blades system and fast rehabilitation of blade in case of out of frame blade
Gobo size: B, outer: 86 mm - image: 64,5 mm - thickness: 1,1 mm
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment
Special features: HB mode, STUDIO mode, SILENT mode
BODY
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: black
|
|
CONTROL
Protocols: DMX512, RDM
DMX channels: 1 / 2 / 3RGB / 4RGBL / 5RGBL / 3 / 4 / 5 / 8 / 13 ch - Tungsten / 3.200 K / 5.400 K / 6.500 Kchannel
RDM: RDM ready for fixture remote monitor and settings
Display: black OLED high resolution display
Firmware upgrade: yes, via USB - DMX interface (UPBOX2) not included
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Strobe / shutter: 1 - 25 Hz, electronic
Battery backup: battery backup for user operation without connecting to the main power
Operating temperature: -20° ~ +45°
Flicker: flicker free operation
Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
Mains power supply: 100-240 V – 50/60 Hz
Max power consumption: 200W
Output (at 230 V): 10 units on a single power line
Power factor: >0,95
PHYSICAL
Cooling: low noise fan
Sospension and fixing: hanging bracket suitable for safe hanging and positioning
Signal connection: Amphenol XLR 5p IN/OUT connectors
Power connection: Neutrik powerCON TRUE1 IN/OUT connectors
IP rating: 20
Dimensions (WxHxD): 265x259x540mm
Weight: 7,3kg
|
