LIGHT SOURCE
Source: 6x4W RGBW LEDs
Luminous flux: 1'030lm
Lux: 916,7lx @3 m full
Source life expectancy: > 50.000 h
OPTICS
Beam angle: 14°
Field angle: 30°
Lens diameter: 38mm
Additional optics: 25° (inc) - 45° (op)
COLOUR SYSTEM
Colour mixing: RGBW / FC
White presets: 3.200 K ~ 10.000K
Colour wheel: virtual colour wheel with presets
Macros: built-in white presets
DYNAMIC EFFECTS
Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment
BODY
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: black
|
|
CONTROL
Protocols: DMX512
DMX channels: 4 / 9channel
W-DMX: optional, proprietary protocol compatible with WIFIBOX, WDBOX
Display: LED display user interface
IR: infrared sensor controlled by remote
Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer: linear 0 ~ 100% electronic dimmer
Strobe / shutter: 1 - 28 Hz, electronic
Operating temperature: -10° ~ +45°
Flicker: flicker free operation
ELECTRICAL
Power supply: 100-240 V – 50/60 Hz
Power consumption (at 230 V): 48W
PHYSICAL
Cooling: passive cooling and fan-free
Sospension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
Data: USB port for USB WIFI transmitter (optional)
Signal connection: XLR 3p IN/OUT connectors
Power connection: IEC IN/OUT connectors
IP rating: 20
Dimensions (WxHxD): 210x173x200mm
Weight: 1,6kg
|
